| Application |
- For cable protection systems in a wide range of applications
|
|
| Characteristics |
- Extremely high impact resistance
|
- Vibration-proof connection to PMAFLEX conduits
|
|
- High conduit pull-out strength
|
- Very good chemical properties
|
- Free from halogens and cadmium
|
- Fits both conduit profiles - fine (T) and coarse (G)
|
|
| General |
Material |
Polyamide 6 |
Color |
Black |
Compatiable With |
PMAFLEX, PMAFLEX Pro, PMA Smart Line |
|
| Dimension Information |
Output fits to conduit size NW |
10 |
Output fits to conduit size - Metric |
12 |
|
| Technical Information |
Temperature Range-Continuous (Celsius) |
-40° C - +105° C |
Temperature-Short-Term (Celsius) |
+160° C |
 Technical Data Sheet |
Click Here |
Chemical Resistance Chart |
Click Here |
|
| IP Ratings |
IP Rating |
IP67 stat. / IP65 dyn.(with NFN3) |
|
| Packaging |
Inner Package |
20 |
Outer Package |
240 |
Package Height |
7.874 |
Package Length |
15.748 |
Package Width |
11.811 |
T&B Sold in UOM |
Each |
T&B Weight Per UOM |
0.03 lbs. Each |
|
| Application Support |
PMA Reference Guide |
Click Here |
Prouduct Overview-PMAFIX Connectors |
Click Here |
PMAFIX Connectors-Safety and Sealing Systems |
Click Here |
|
| Certifications |
RoHS Compliance |
Yes Generate Compliance Certificate |
