| Application |
- For cable protection systems in a wide range of applications
|
- Excellent fire characteristics allow application in public buildings such as hospitals, hotels, airports, train and subway stations, shopping centers, etc.
|
|
| Characteristics |
- Extremely high impact resistance
|
- Vibration resistant connection to PMAFLEX conduits
|
|
- High conduit pull-out strength
|
- Very good chemical properties
|
- Free from halogens and cadmium
|
- Fits conduit profile coarse (G)
|
|
| General |
Material |
Polyamide 6 |
Color |
Black |
Thread Type |
Metric |
Compatiable With |
PMA FLEXPLus |
|
| Dimension Information |
Fits to Conduit Size (NW) |
17 |
Fits to Conduit Size (metric) |
20 |
Fits to Conduit Size (inches) |
1/2 |
Thread Size (Metric) |
M20 x 1.5 |
|
| Technical Information |
Temperature Range-Continuous (Celsius) |
-40 degree C to +105 degree C |
Temperature-Short-Term (Celsius) |
+160 degree C |
 Technical Data Sheet |
Click Here |
Chemical Resistance Chart |
Click Here |
|
| Specifications |
NEMA Rating |
NEMA 6P stat./ NEMA 6 dyn. |
|
| IP Ratings |
IP Rating |
IP68 stat. / IP67 dyn. |
|
| Packaging |
Inner Package |
50 |
Outer Package |
250 |
Package Height |
7.874 |
Package Length |
15.748 |
Package Width |
11.811 |
T&B Sold in UOM |
Each |
T&B Weight Per UOM |
0.35 lbs. Each |
|
| Application Support |
PMA Reference Guide |
Click Here |
Product Overview-FIXPLus Fittings |
Click Here |
Prouduct Overview-PMAFIX Connectors |
Click Here |
|
| Certifications |
RoHS Compliance |
Yes Generate Compliance Certificate |
