Features
A minimum .040 in. (40 mil) PVC coating on the exterior.
A nominal .002 in. (2 mil) blue urethane on the interior.
Color coded thread protectors on each end.
Blue urethane coating over Hot-Dip Galvanized threads.
General
Material	Aluminum
Color	Light Blue
Thread Protector Color	Black
Dimension Information
Pipe Size (Metric Size Designator*)	63
Size (inches)	2 1/2
O.D. Steel Only (inches)	2.875
O.D. Steel Only (mm)	73.0
O.D. with PVC (inches)	2.955
O.D. with PVC (mm)	75.0
Nominal Wall Thickness-Steel Only (inches)	0.193
Nominal Wall Thickness-Steel Only (mm)	4.90
Nominal Wall Thickness with PVC (inches)	0.233
Nominal Wall Thickness with PVC (mm)	5.91
Nominal Inside Diameter (inches)	2.489
Nominal Inside Diameter (mm)	63.2
Cross Section Area (square inches)	4.788
Cross Section Area (mm)	121.61
Length without Couplings	9' 10-1/2"
Length without Couplings (mm)	3.01
Minimum Weight Per Foot (lbs)	5.27
Minimum Weight Per Foot (kil)	239.05
Technical Information
Chemical Resistance Chart	Click Here
Specifications
Ocal Specification Guide-1995 Master Format	Click Here
Ocal Specification Guide-1995 Master Format	Click Here
Ocal Specification Guide-2004 Master Format	Click Here
Ocal Specification Guide-2004 Master Format	Click Here
Packaging
Order Multiple	10
Inner Package	10
Outer Package	170
Package Height	9
Package Length	120
Package Width	18.5
T&B Sold in UOM	Feet
T&B Weight Per UOM	2.06 lbs. Each
Application Support
T&B Sales Drawings	wsd-000544
Ocal PVC Coated Conduit System	Click Here
Ocal Specifications	Click Here
Recommended Installation Procedures	Click Here
NEMA Standards-RN 1	Click Here
NEC 310-16 - Conductors for General Wiring	Click Here
NEC Table 8	Click Here
Notes
Metric size designator (ANSI C80. 1-1994)
Coupling(s) shipped with conduit are packaged separately
Certifications
RoHS Compliance	Yes   Generate Compliance Certificate
