| Features |
- Flame-retardant, cross-linked polyolefin.
|
- Meets UL 224, 125°C; CSA 22.2 No. 198.1, 125°C; MIL-DTL-23053/5 Class 1&2; AMS 3636 & 3637; DEF STAN 59-97, Issue 3, Type 2a
|
|
| General |
Style |
CPO Series Non-Lined |
Color |
Black |
Temperature Range |
-55°C - 135°C |
Shrink Ratio |
2:1 |
|
| Dimension Information |
Length (feet) |
100 |
Minimum Expanded I.D. (inches) |
1 |
Maximum Recovered I.D. (inches) |
0.5 |
Nominal Recovered Wall (inches) |
0.035 |
Cable Range |
2/0 - 350 MCM |
|
| Specifications |
Shrink Temperature |
120°C |
|
| Packaging |
Outer Package |
1 |
Package Height |
3.9 |
Package Length |
13.3 |
Package Width |
13.3 |
T&B Sold in UOM |
Each |
T&B Weight Per UOM |
560 lbs. per 100 |
|
| Application Support |
 Specifications |
Click Here |
Overview |
Click Here |
|
| Notes |
- Order multiple is for 4 ft. sticks is 25 sticks. Order multiple for reels is 1 reel. When ordering standard package, order by package not feet.
|
- UL Recognized File Number E137759 and CSA Certified. Clear material not UL Recognized.
|
- Larger diameters available upon special request; consult Customer Service.
|
|
| Certifications |
RoHS Compliance |
Yes Generate Compliance Certificate |
