| Features |
- Waterproof construction provides environmental separation at the front of each device (they don't have to be connected together just to be called "watertight").
|
- Two optional pilot/control pins for contractors, load monitor circuits, shunt trip or any other communication functions you need.
|
- Center ground contacts: make FIRST, break LAST
|
- All receptacles and connectors have a gated hotating disk on the face of the interior, engaged on insertion.
|
|
| Application |
- Electrical hook-up of mobile medical imaging (MMI) trailers.
|
- For use in applications where outdoor, severe or high abuse environments exist.
|
- Electrical hook-up of mobile medical imaging (MMI) trailers.
|
|
| General |
Style |
Load Breaking Female Connector |
Material |
Copper Free, Cast Aluminum, Epoxy Powder-Coated Housing |
Material_1 |
Standard Neoprene O-ring interior components |
Frequency |
60 Hz |
Amperage |
200 Amp |
Pole/Wire |
4P/5W |
System |
Heavy Industrial & Marine |
Voltage |
3 PhaseY 347/600 Volts AC |
|
| Dimension Information |
 Overall Dimensions |
Click Here |
|
| Specifications |
Engineering Specifications |
Click Here |
|
| Packaging |
Outer Package |
1 |
Package Height |
8 |
Package Length |
15 |
Package Width |
8 |
T&B Sold in UOM |
Each |
T&B Weight Per UOM |
16.8 lbs. Each |
|
