| Features |
- Produced from seamless electrolytic copper tubing which provides high conductivity and minimizes voltage drop.
|
- Tin-Plated to resist corrosion.
|
|
| General |
Style |
Copper Lugs |
Material |
Copper |
Finish |
Tin-Plated |
Wire Size - Str. |
600 |
|
| Dimension Information |
Bolt Size (inches) |
1/2 |
B (inches) |
2 5/8 |
C (inches) |
5/8 |
H (inches) |
2 3/16 |
L (inches) |
6 3/4 |
P (inches) |
3 1/8 |
S (inches) |
1 3/4 |
W (inches) |
1 11/16 |
|
| Tooling |
Installing Dies |
1 1/8-1,22,96 |
|
| Notes |
- The 'N' suffix on the catalog number indicates NEMA bolt spacing of 1 3/4"
|
- For other available sizes, please consult your Thomas & Betts representative.
|
|
| Certifications |
Standards Compliant |
UL listed and CSA certified. |
