Application
Rail/Infrastructure
Railways
Public Buildings
Underground
Characteristics
Very high UV resistance
High flexibility
High fatigue life
High abrasion resistance
Self-extinguishing
Halogen free
Super low fire hazard
General
Material	Polyketone
Material-Conduit Core	Non-Metallic
Color	Black
System	Hi-Spec Non-Metallic
Compatiable With	Type PK Fittings
Dimension Information
Size (inches)	5/16
Minimum Bend Radius (inches)	1.38
Conduit Size NW (mm)	10
Conduit Size Metric (mm)	13
Inside Diameter (inches)	0.39
Outside Diameter (inches)	0.51
Inside Diameter (mm)	10
Outside Diameter (mm)	14.1
Technical Information
Temperature Range-Continuous (Celsius)	-45 to +260
Fatigue Life	High
Technical Data Sheet	Click Here
Chemical Resistance Chart	Click Here
IP Ratings
IP66 when used with fitting Type PK-Type A
IP67 when used with fitting Type PK-Type A
Packaging
Outer Package	1
T&B Sold in UOM	Each
T&B Weight Per UOM	1.38 lbs. Each
Application Support
Product Overview-Cutting Tools	Click Here
Product Overview-HI-SPEC Non-Metallic Flexible Systems	Click Here
Quick Select Guide-Non-Metallic Systems	Click Here
Certifications
RoHS Compliance	Yes   Generate Compliance Certificate
