| Features |
- No Tools, No Screws Necessary with EZ Click assembly; Easy Action Single-Wiring Point Access; Simple Cable Clamping, One-piece EZ Tite assembly; Grip Tite safety
|
|
| Application |
- Used for Beverage Plants, Construction Sites, Food Processing, Marine and Shipboard, Pulp and Paper Mills, Chemical Plants
|
- Used for Beverage Plants, Construction Sites, Food Processing, Marine and Shipboard, Pulp and Paper Mills, Chemical Plants
|
|
| General |
Style |
Watertight Plug |
Material |
Housing, Contact Carriers, Cable Gland Nut and Mounting Flanges are Valox |
Material_1 |
Pin and Sleeves of Nickel Plated Brass |
Amperage |
20 Amp |
 Amp Ratings |
Click Here |
Pole/Wire |
3P/4W |
System |
Washdown Industrial & Light Marine |
Voltage |
3 Phase 480 Volts AC |
|
| Dimension Information |
Overall Dimensions |
Click Here |
UniGard_Dimensions |
Click Here |
|
| Specifications |
Engineering Specifications |
Click Here |
|
| Packaging |
Outer Package |
1 |
Package Height |
4.63 |
Package Length |
8.63 |
Package Width |
4.75 |
T&B Sold in UOM |
Each |
T&B Weight Per UOM |
0.6 lbs. Each |
|
| Application Support |
Overview |
Click Here |
Russellstoll Application Guide |
Click Here |
|
| Certifications |
RoHS Compliance |
Yes (exemption 06) Generate Compliance Certificate |
Certifications |
IP67 |
