| Application |
- For cable protection systems in a wide range of applications
|
|
| Characteristics |
- Very high impact resistance
|
- Vibration proof connection to PMAFLEX conduits
|
- High conduit pull-out strength
|
- Very good chemical properties
|
- Free from halogens and cadmium
|
- Fits both conduit profiles - Fine (T) and coarse (G)
|
- Easy installation, simply push the conduit in
|
- Can be easily re-opened with a screwdriver
|
|
| General |
Material |
Polyamide 6 |
Color |
Grey |
Thread Type |
NPT |
Compatiable With |
PMAFLEX, PMA Smart Line |
|
| Dimension Information |
Fits to Conduit Size (NW) |
29 |
Fits to Conduit Size (metric) |
32 |
Fits to Conduit Size (inches) |
1 |
Thread Size (NPT) |
1 |
|
| Technical Information |
Temperature Range-Continuous (Celsius) |
-40 degree C to +105 degree C |
Temperature-Short-Term (Celsius) |
+160 degree C |
 Technical Data Sheet |
Click Here |
Chemical Resistance Chart |
Click Here |
|
| IP Ratings |
IP Rating |
IP66 stat. / IP54 dyn. |
|
| Packaging |
Order Multiple |
20 |
Inner Package |
20 |
Outer Package |
360 |
Package Height |
0.01 |
Package Length |
0.01 |
Package Width |
0.01 |
T&B Sold in UOM |
Each |
T&B Weight Per UOM |
0.06 lbs. Each |
|
| Application Support |
PMA Reference Guide |
Click Here |
Prouduct Overview-PMAFIX Connectors |
Click Here |
PMAFIX Connectors-Safety and Sealing Systems |
Click Here |
|
| Certifications |
RoHS Compliance |
Yes Generate Compliance Certificate |
